The RAM® Universal Composite Marine Electronic Mount with 1.5" C Size ball and short double socket arm delivers a compact, durable mounting solution for marine electronics and other sensitive devices. This mount combines a drill-down flat base, short arm, and universal rectangular top plate to create a stable platform for marine environments and vibration-heavy applications.
Constructed from high-strength composite and engineered for corrosion resistance, this mount is ideal for boats, marine electronics, GPS units, fish finders, chart plotters, and other electronic devices requiring a secure and adjustable mounting solution.
If purchasing from Gadget Mounts, you can be confident knowing we are an Authorized RAM Mounts Dealer.
Features
• Rectangular 2" x 2.25" drill down flat surface base with 1.5" ball - Hole pattern: 1.5" x 2"
• 1.5" C Size ball provides strong holding power and smooth articulation
• Universal 6.25" x 2" top plate supports multiple marine electronics hole patterns
• AMPS-compatible bottom base for standardized mounting
• Compact short arm design reduces vibration and movement
• High-strength composite construction for marine durability
• Supports horizontal or vertical mounting surfaces
• Made in the USA
• Backed by RAM lifetime warranty
Ideal Applications
• Marine GPS units
• Fish finders and sonar displays
• Chart plotters
• Marine radios and small electronic displays
• Other devices requiring universal plate mounting
Specifications
Ball Size: C Size (1.5")
Bottom Plate Size: 2" x 2.25"
Top Plate Size: 6.25" x 2"
Bottom Hole Pattern: 4-Hole AMPS – 1.181" x 1.496"
Base Drill Pattern: 1.5" x 2"
Arm Type: Short Double Socket Arm
Overall Height (Fully Straight): 5.75"
Arm Length (Overall): 3.56"
Socket to Socket Length: 2.5"
Weight Capacity (Standard Use): 4 lbs
Weight Capacity (Heavy-Duty Use): 3 lbs
Material: High Strength Composite
Product Weight: 0.75 lbs
Mounting Orientation: Horizontal or Vertical Surface Compatible
Additional Notes: Universal plate includes multiple hole locations. Some applications may require additional drilling.
What's Included
• (1) Drill-Down Flat Surface Base with C Size Ball
• (1) Short Double Socket Arm
• (1) Universal Rectangular Top Plate
Drill-down mounting screws are not included. Common mounting screw sizes may include #8, #10, M4, or M5 depending on mounting surface
Brand and Warranty
Brand: RAM Mounts
Part Number: RAP-111-B
Warranty: Manufacturer Lifetime Warranty
