Description
The RAM-B-309-8U is a motorcycle base kit with two B Size 1" RAM balls. It can mount to a brake/clutch reservoir or to a handlebar using the included U-bolt hardware.
Key Features
- Dual B Size 1" RAM ball base
- Mounts to brake/clutch reservoirs or handlebars
- Fits rails from 0.5" to 1.25" in diameter
- Includes standard and metric hardware
- Marine-grade aluminum construction
Use Cases & Compatibility
Designed for motorcycle mounting applications where a RAM B Size 1" ball connection is needed at the handlebar or brake/clutch reservoir. Compatible with RAM B Size double socket arms and related 1" ball components.
Specifications
Ball Size: B Size 1" Ball
Material: Marine-grade aluminum
Clamp Range: 0.5" to 1.25" diameter
Weight Capacity: Standard Use: 2 lbs; Heavy-Duty Use: 1 lb
Product Weight: 0.33 lb
What’s Included
- RAM double 1" ball base
- Assembly hardware
- Two M6 x 55mm hex bolts
- Two 1/4"-20 x 2" hex bolts
- Two 1/4"-20 x 2.5" hex bolts
- Two 1/2" spacers
- Two 1/4" split lock washers
- One 1/4"-20 U-bolt for 0.5" to 1" rails
- One 1/4"-20 U-bolt for 1" to 1.25" rails
- Two 1/4"-20 Nylock nuts
- Two rubber caps
- One U-bolt spacer
Brand & Warranty
Brand: RAM Mounts
Manufacturer Part Number: RAM-B-309-8U
Warranty: Manufacturer's lifetime warranty
Gadget Mounts is an Authorized RAM Mounts Dealer.
